Structural elements used in satellite payloads must maintain absolute dimensional stability across extreme temperature fluctuations in space. For this project, the client required structural spacers machined from Invar 36, a nickel-iron alloy celebrated for its uniquely low coefficient of thermal expansion. However, Invar 36 is highly susceptible to introducing internal structural stresses during heavy machining, which can lead to unpredictable dimensional warping over time if left unmanaged.
The production cycle utilized a tightly controlled sequence that integrated precision machining with inter-stage thermal stress-relief profiling. Rough machining was executed on advanced 5-axis CNC milling platforms to establish the primary geometry while leaving a precise allowance for finish grinding and milling. The components were then subjected to multi-stage heat treatments to stabilize the crystalline matrix of the alloy before receiving final high-precision finish cuts to achieve tight geometric tolerances.
Final quality verification was performed inside the climate-controlled inspection lab using the ZEISS CONTURA coordinate measuring machine (CMM). The inspection confirmed that all true-position tolerances, flatness, and perpendicularity requirements met space-flight specifications. The delivery of these dimensionally stable Invar spacers verified the company’s adherence to AS9100 aerospace quality standards for space-bound payloads.
